MP-MU44-3.2
MP-MU44-3.2 is a 4x4 USB 3.2 Matrix. It allows 4 x USB devices to be shared between 4 x host devices, supporting Plug-and-Play. The USB data transfer rate is up to 5Gbps. It provides advanced features including a web interface module for control and configuration of the Matrix, along with RS-232 for seamless control integration
- Support USB 3.2 gen 1
- Data transfer rates up to 5Gbps
- Backwards compatible with USB 2.0 and 1.1
- Support front panel, GUI, IR and RS232 control
- 5V900mA power supply via USB-A
- Web interface module for control and configuration of the MP-MU44-3.2
- Plug and Play
Powered by Froala Editor
| Input | |
| Input Port | 4 x USB |
| Connector | 4 x USB-A |
| USB Standard | USB3.2 Gen1 |
| Output | |
| Output Port | 4 x USB |
| Connector | 4 x USB-B |
| USB Standard | USB3.2 Gen1 |
| Control | |
| Port | 1x IR IN, 1 x RS232, 1 x TCP/IP |
| Connector | 1 x 3.5mm mini jack, 1 x 3-pin terminal blocks, 1 x RJ45 |
| General | |
| Bandwidth | 5Gbps |
| Operation Temperature | -10 ~ +55°C |
| Storage Temperature | -25 ~ +70°C |
| Relative Humility | 10% - 90% |
| Power Supply | DC24V1.25A |
| Power Consumption | 20.4W(Max) |
| Dimension (W*H*D) | 200mm x 39mm x 153mm |
| Net Weight | 840g |
